Smart Pro Tower UPS System - NAFTA assembled

version of SMART700

MODEL NUMBER: SM700NAFTA

Description

Tripp Lite's SM700NAFTA intelligent, line interactive UPS system protects servers, networking accessories and

telecommunications equipment from blackouts, voltage fluctuations and transient surges. Large internal batteries

offer 20 minutes half load runtime and 6 minutes at full load during power failures. 700VA/450 watt power

handling capability supports a variety of networking, telecom and various other application types, including the

support of multiple network workstations. Includes a total of 6 UPS supported outlets. Supports remote

monitoring of UPS and site power conditions via built-in USB monitoring port. Includes PowerAlert UPS

monitoring and unattended shutdown software with complete cabling. Built-in audible alarm and 5 front panel

LEDs indicate status of line power, battery power, battery low/replace, voltage regulation and load level. Wall

mountable with UPSWM wallmount bracket. Network-grade AC surge suppression protects equipment from

damage and performance problems resulting from transient surges. Attractive, small-footprint tower housing uses

less than 53 square inches of floor or desktop space. Two year warranty with $250,000 connected equipment

insurance .

Features

700VA/450 watt power handling capability supports a variety of networking, telecom and various other

application types

Built-in voltage regulation and battery support, plus complete AC line surge suppression prevents equipment

damage, data loss and downtime

Large internal batteries offer 20 minutes half load runtime and 6 minutes at full load during power failures

Automatic Voltage Regulation (AVR) circuits with two boost and one voltage reduction level maintains usable

120V nominal output over an input voltage range of 75-147V

Includes a total of 6 NEMA5-15R outlets

Includes USB communications port for remote monitoring of UPS status and site power conditions

Communications port enables safe unattended shutdown without data loss during extended power failures

Communications port supports messaging of UPS and line power status, including on-battery, low-battery,

power-restored, AC line voltage, DC battery voltage and battery capacity

Communications ports support timed inverter shutoff after unattended shutdown, activate self-test and 10

second reboot of connected equipment

PowerAlert UPS monitoring and unattended shutdown software with complete cabling included

Highlights

700VA line interactive tower UPS

system for 120V network

applications

Enhanced USB communications

port, free software and cabling

Corrects brownouts and

overvoltages from 75 to 147V

6 outlets

$250,000 Ultimate Lifetime

Insurance (USA, Puerto Rico &

Canada only)

Applications

Ideal for the protection of

fileservers, network accessories

and telecommunications

equipment. Common applications

include any mix of servers,

workstations, hubs, routers,

concentrators, IP telephony and

traditional PBX switching

systems. Ideal for sensitive

electronic applications in areas

where brownouts and

overvoltages are common.

Package Includes

SM700NAFTA UPS System

Monitoring cable

PowerAlert unattended shutdown

and UPS/Power monitoring

software

Instruction manual with warranty

information

Battery replacement door

Supports Tripp Lite's WatchDog software application to restore unresponsive programs by automatically restarting them and rebooting completely locked

computers by automatically switching UPS power off and back on again

Notification of system status via 5 LEDs and multi-function audible alarms

Wall mountable with UPSWM wallmount bracket

Attractive small footprint black tower housing uses less than 53 square inches

Hot-swappable batteries allow on-site battery replacement

Cold start capability enables UPS turn-on in battery mode during blackout conditions

UL (USA), cUL (Canada), NOM (Mexico), Class A (Emissions) Listed

$250,000 Ultimate Lifetime Insurance .
